Shared size platform
Standard size platforms include 40, 100, 400, 800 and 926 L vertical or horizontal configurations.
QDBG CHINAGas cylinders & gas equipmentRequest a Quote Chemical and refrigerant service
Product family 06Welded Chemical & Refrigerant Cylinders
QDBG CHINA supplies welded steel cylinders for liquid chlorine, liquid ammonia, sulfur dioxide, refrigerant and selected chemical media. The cylinder size platform may be shared, while pressure, filling ratio, valve, outlet, coating, marking and filling system are confirmed for the intended medium.
Real QDBG product photographyProduct overview
Configured to the application—not selected from a label alone.
The 40–926 L welded steel size platform supports selected liquefied chemical and refrigerant media. The cylinder body platform may be shared, but the complete service configuration is approved for one intended medium.
Medium-specific system
Pressure, filling ratio, valve and outlet are matched to the intended chemical or refrigerant medium.
Order configuration
Installation, supports, coating, marking, handling features and packing follow the approved order design.
Product / series range
Choose the relevant supply path.
Use these series as a starting point. Final technical values are confirmed against the selected model and destination requirements.
01
Liquid Chlorine Cylinders
QF-10 valve configurations for approved liquid chlorine service.
Discuss requirement →02Liquid Ammonia Cylinders
QF-11 valve configurations for fertilizer, refrigeration and chemical use.
Discuss requirement →03Refrigerant & Chemical Media
Medium-specific configurations selected by compatibility, pressure and filling ratio.
Discuss requirement →Welded steel product range
One size platform, configured for the intended medium.
Choose the cylinder capacity and installation form first. Pressure, filling ratio, valve, outlet, coating and filling system are then matched to the confirmed medium.
Vertical and horizontal cylinder configurations
Compact 40 L and 100 L cylinders are designed for vertical service. The 400 L, 800 L and 926 L platforms use horizontal installation for industrial storage, distribution and process supply.
Discuss your medium and capacity →Standard size platforms
40–926 L · GB/T 5100 series| Water capacity | Outside diameter | Height / length* | Nominal wall | Approx. weight | Installation |
|---|---|---|---|---|---|
| 40 L | Ø300 mm | Approx. 845 mm | 6 mm | Approx. 40.1 kg | Vertical |
| 100 L | Ø400 mm | Approx. 1060 mm | 6 mm | Approx. 72 kg | Vertical |
| 400 L | Ø600 mm | Approx. 1800 mm | 8 mm | Approx. 250 kg | Horizontal |
| 800 L | Ø800 mm | Approx. 2000 mm | 10 mm | Approx. 445 kg | Horizontal |
| 926 L | Ø800 mm | Approx. 2255 mm | 10 mm | Approx. 512 kg | Horizontal |
* Height or length excludes the valve. Dimensions and weights describe the standard size platform; final values follow the approved medium-specific drawing.
Select by medium
Pressure and valve configuration follow the filling medium.
A cylinder approved for one medium must not be treated as automatically interchangeable with another medium, even where the body dimensions are similar.
Liquid Chlorine Welded Steel Cylinders
Welded steel cylinders configured for liquid chlorine service, with pressure rating, filling ratio, valve, outlet, coating and handling arrangement confirmed as one complete system.
View service details →Liquid Ammonia Welded Steel Cylinders
Vertical and horizontal welded steel cylinders configured for liquid ammonia storage, filling and industrial refrigeration supply.
View service details →
Refrigerant & Chemical Media Welded Cylinders
Welded steel cylinder platforms for selected refrigerant and chemical media, engineered around compatibility, pressure, filling ratio, valve interface and destination requirements.
View service details →Medium configuration guide
Pressure · filling ratio · valve · design life| Medium | Formula | WP | TP | Filling ratio | Valve | Outlet | Design life |
|---|---|---|---|---|---|---|---|
| Liquid Ammonia | NH₃ | 3 MPa | 4.5 MPa | 0.53 kg/L | QF-11 | G1/2 | 12 years |
| Liquid Chlorine | Cl₂ | 2 MPa | 3 MPa | 1.25 kg/L | QF-10 | G3/4* | 12 years |
| Sulfur Dioxide | SO₂ | 2 MPa | 3 MPa | 1.23 kg/L | QF-10 | G3/4 | 12 years |
Additional refrigerant and chemical media15 configurations
| Medium | Formula | WP | TP | Filling ratio | Valve | Outlet | Design life |
|---|---|---|---|---|---|---|---|
| Hexafluoropropylene (R-1216) | C₃F₆ | 2 MPa | 3 MPa | 1.06 kg/L | QF-10 | G3/4 | 20 years |
| Methyl Chloride | CH₃Cl | 2 MPa | 3 MPa | 0.81 kg/L | QF-10 | G3/4 | 20 years |
| Chlorotrifluoroethylene (R-1113) | C₂ClF₃ | 2 MPa | 3 MPa | 1.1 kg/L | QF-10 | G3/4 | 20 years |
| Methyl Bromide | CH₃Br | 2 MPa | 3 MPa | 1.5 kg/L | QF-10 | G3/4 | 20 years |
| Hydrogen Fluoride | HF | 2 MPa | 3 MPa | 0.83 kg/L | QF-10 | G3/4 | 12 years |
| Ethyl Chloride | C₂H₅Cl | 1 MPa | 1.5 MPa | 0.82 kg/L | QF-10 | G3/4 | 20 years |
| Ethyl Bromide | C₂H₅Br | 1 MPa | 1.5 MPa | 1.28 kg/L | QF-10 | G3/4 | 20 years |
| Methylamine | CH₃NH₂ | 1 MPa | 1.5 MPa | 0.6 kg/L | QF-11 | G1/2 | 12 years |
| Dimethylamine | (CH₃)₂NH | 1 MPa | 1.5 MPa | 0.58 kg/L | QF-11 | G1/2 | 12 years |
| Trimethylamine | (CH₃)₃N | 1 MPa | 1.5 MPa | 0.56 kg/L | QF-11 | G1/2 | 12 years |
| Ethylamine | C₂H₅NH₂ | 1 MPa | 1.5 MPa | 0.62 kg/L | QF-11 | G1/2 | 12 years |
| Ethyl Vinyl Ether | C₄H₈O | 1 MPa | 1.5 MPa | 0.67 kg/L | QF-10 | G3/4 | 20 years |
| Ethylene Oxide | C₂H₄O | 1 MPa | 1.5 MPa | 0.79 kg/L | QF-19 | G3/4 | 20 years |
| Boron Trichloride | BCl₃ | 1 MPa | 1.5 MPa | 1.2 kg/L | QF-10 | G3/4 | 12 years |
| Methanethiol | CH₃SH | 1 MPa | 1.5 MPa | 0.78 kg/L | QF-10 | G3/4 | 12 years |
* Existing 40 L and 100 L liquid-chlorine configurations may use G1/2; larger chlorine designs commonly use G3/4. Final compatibility, filling practice, valve outlet, service life and documentation are confirmed before production.
Reference data
Technical selection guide
Published values describe the available product family. The final drawing, dimensions, pressure, valve, marking and certification follow the confirmed model and order.
- Capacity range
- 40 / 100 / 400 / 800 / 926 L standard platforms
- Typical media
- Liquid chlorine, liquid ammonia, sulfur dioxide, refrigerants and selected chemical media
- Installation
- 40–100 L vertical; 400–926 L horizontal
- Pressure range
- 1.0–3.0 MPa working pressure, medium-specific
- Valve options
- QF-10 / QF-11 / QF-19 or other approved configuration
- Standard basis
- GB/T 5100 series; final compliance by approved design
Quick selection guide
What the buyer should confirm
- Contained medium and application
- Required capacity and filling basis
- Valve arrangement and handling method
- Drawing, standard, inspection and destination
Configuration options
Order-specific choices
- Single or multiple valve arrangements
- Guards, supports and lifting features
- Marking and surface finish
- Inspection and packing where applicable
Typical applications
Built around real operating requirements.
STANDARD FAMILIESGB/T 5100 · Medium-specific approved design · Order-specific inspection
Availability depends on the selected model, certificate scope and destination-market requirements. Please confirm the required approval before ordering.
